SPECIFICATII

Putere

• Total Max Power: 320W

Putere RMS

• Pe canal la 4ohms (?1%THD+N): 2 x 50W
• Pe canal la 2ohms (?1%THD+N): 2 x 75W
• In punte la 4ohms (?1%THD+N): 1 x 150W

Setarea sunetului

• Crossover Frequency (Fix, OFF/LPF/HPF Selectable) 1/2 ch: 80 Hz (-18dB/oct)
• EQ (Equalizer): Bass EQ Fixed Frequency 50 Hz _ Selectable Gain 0/+6/+12 dB

Dimensiuni

• Baza : 210 mm x 60 mm x 242 mm

General

• Power Requirements: 14.4 V DC (11 V to 16 V)
• Input Sensitivity: 0.2 - 4.0 V (RCA IN)
• Input Impedance: RCA IN 10k ? / SP IN 10k ?
• Frequency Response: 10 Hz - 50 kHz (+ 0,-1 dB)
• Speaker Impedance: 4 or 2 ?
• Signal to Noise: S/N Ratio (IHF A Weighted, Reference: rated power into 4ohms) 90 dB
• Greutate: 2.0 Kg
