SPECIFICATIONS

RMS Power Ratings

• Per channel into 4 Ohms: (@14.4V ≤1%THD+N) 1200W x 1
• Per channel into 2 Ohms: (@14.4V ≤1%THD+N) 1200W x 1

Sound Tuning

• Crossover: Variable, 50-400Hz (-24dB / oct ), (Variable, L.P.F Only 1/2 ch)
• Subsonic Filter: OFF / 15Hz / 30Hz

Dimensions

• Heat Sink (WxHxD) mm: 257mm x 192mm x 50.8mm

General

• Power Requirements: 14.4V DC (11V to 16V)
• Input Sensitivity: Select Vol, 0.1V to 1.0V or 1.0V to 8.0V (For Rated Power)
• Cable size: 25 mm² (BATT and GND), 4 mm² (Remote), Up to 10 mm² (Speaker)
• Frequency Response: 5 Hz - 400 kHz / 0dB ~ -3dB (Reference: 1 W into 4 Ω)
• Speaker Impedance: 4 or 1 Ω
• Signal to Noise: CEA 2006 S/N Ratio (IHF A Weighted, Reference: 1W into 4Ω) 92 dBA
