SPECIFICATIONS

Max Power Output Ratings

• Total Max Power: 1300W

RMS Power Ratings

• Per channel into 4 Ohms: (@14.4V ≤1%THD+N) 450W x 1
• Per channel into 2 Ohms: (@14.4V ≤1%THD+N) 650W x 1

Sound Tuning

• Crossover: Variable LPF, 50-400Hz (-24dB / oct )
• Subsonic Filter: Variable, 8-40Hz (-24dB / oct )

Dimensions

• Heat Sink (WxHxD) mm: 228.5mm x 165mm x 50.8mm

General

• Power Requirements: 14.4V DC (11 - 16V)
• Input Sensitivity (RCA Input): 0.1 - 4.0V
• Input Impedance: >10k ohms
• Frequency Response (+0, -3dB: 1W into 4 ohms): 8Hz - 400Hz
• Frequency Response (+0, -1dB: 1W into 4 ohms): 10Hz - 300Hz
• THD+N (10W into 4 ohms): ≤0.02%
• THD+N (Rated Power into 4 ohms): ≤0.07%
• Damping Factor (10W into 4 ohms at 100Hz): >1300
• Signal to Noise (Rated Power into 4 ohms): >113dB
• Weight: 2.4kg
