Caracteristici tehnice:
Tuner
Memory Pre-sets: Pre-set Stations (FM:18, AM:12)
Memory: Auto Memory
Seek Mode: Local
RDS
RDS Functions: AF, TA, TP, PTY, NEWS, EON
BLUETOOTH®
Built-in BLUETOOTH®
Hands Free Calling: HFP (Hands Free Profile)
Streaming Music: A2DP (Advanced Audio Distribution Profile) Compatible
Streaming Music Control: AVRCP (Audio/Video Remote Control Profile) Compatible
Phone Book Synchronization
Phone Book Search: Alphabet search
Speed Dial: 6 Pre-set Memory
Voice Dial Operation (depends on mobile phone)
Auto Answer
Call Waiting
Call History Display: Dialled Call
Redial Function
Speech Volume Level Adjustment: Possible for Outgoing and Incoming Volume
Signal Strength Indicator
Microphone Included
Made for iPod® / iPhone®
Compatibility for iPod/iPhone: Made for iPod touch 5th/4th/3rd Gen., iPod nano 7th/6th/5th Gen., iPod classic 160GB/120GB/80GB, iPhone:6S, 6S Plus, 6, 6 Plus, 5, 5S, 4S, 4, iPhone 3GS
Connection: USB Connection
Music Playback
Available Selections: Playlist, Artist, Album, Song, Podcast, Genre, Composer
Alphabet Search
Direct iPod/iPhone Control
M.I.X. (Shuffle) Play: Song, Album
Repeat
Battery Charging
App mode for iPod Touch, iPhone (from iOS 4)
Disc Player
Disc Type: DVD/CD Player
Disc Playback Type: DVD-Video, DVD±R/RW, CDDA, CD-R/RW, Video CD
Playable Format: MP3/Xvid/MPEG-4/JPEG
M.I.X. Random Play
Repeat
DVD Direct Menu Control
CD Text Display
24 Bit DAC
USB Media Connection
Music & Video Playback Compatible
Playable Format: MP3/Xvid/MPEG-4/JPEG
USB Class: Mass Storage Class
Folder Up/Down
Banking: Max. 256 folders, 2000 songs
Sound Tuning
Subwoofer Level Adjustment
Subwoofer System Select: Subwoofer Level Control Management
High Pass Filter / Low Pass Filter
3 Band EQ (10 pre-sets + custom)
General
Power Output: 4 x 50 W High Power Amplifier
Display: 6.2 inch WVGA High Resolution Display
Control Type: Touch Screen and Rotary Encoder
Face Colour: Black
Blue Illumination
PreOut: 2 PreOuts (2V, Front + Rear/Subwoofer)
AUX-Out: 1 Video Aux Output
AUX-In: Front Aux Input (for Audio, 3.5mm mini jack), 1 A/V Aux Input
Steering Wheel Remote Control Ready (requires additional Alpine interface)
Remote Control Ready
Camera Connection: RCA Connection Compatible
Clock
Auto Dimmer
Security Code Anti-theft
Detachable 2DIN Size Trim Plate
Remote Turn-On
Remote control included: RUE-4233
Microphone included
The IVE-W560BT features an English, German and French interface
The IVE-W560BT-R features an English, Russian and Italian interface
SPECIFICATIONS
Screen
Screen Size: 6.2 inch Wide VGA Screen
LCD Type: Wide LCD colour monitor
Operation System: TFT Active Matrix
Number of Picture Elements: 1,152,000 pixels
Colour system: PAL/NTSC/SECAM/PAL-M automatic select
Max Power Output Ratings
Max Power Output: 4 x 50W
FM Tuner
Tuning Range: 87.5 - 108.0 MHz
Antenna (aerial) terminal: External antenna (aerial) connector
Usable Sensitivity: 10 dBf
Selectivity: 70 dB at 400 kHz
Signal-to-Noise Ratio: 70 dB (mono)
Separation at 1 kHz: 30 dB
Frequency response: 20 – 15,000 Hz
AM Tuner
Tuning Range: 531 - 1,602 kHz
Antenna (aerial) terminal: External antenna (aerial) connector
Intermediate frequency: 9,267 kHz or 9,258 kHz/4.5 kHz
Sensitivity: 44 μV
Disc Player
Frequency Response: 20 - 20k Hz
Total Harmonic Distortion: 0.05%
Wow & Flutter (%WRMS): B.M.L. (Below measurable limit)
Signal-to-Noise Ratio: 80 dB
Video Signal-to-Noise Ratio: DVD: 60 dB
MP3 Decoding: MPEG-1/2 AUDIO Layer-3
WMA Decoding: Windows Media™ Audio
Xvid Decoding: “.avi” ,“MPEG 4” File
USB
USB Requirements: USB 1.1 / 2.0
Max. Power Consumption: 1,000 mA
USB Class: Mass Storage Class
File System: FAT 12/16/32
Frequency Response: 20 - 20k Hz (±1 dB)
Channel Separation (at 1kHz): 75 dB
Dynamic Range (at 1kHz): 95 dB
Total Harmonic Distortion (at 1kHz): 0.01%
Wow & Flutter (%WRMS): B.M.L.
Signal-to-Noise Ratio: 80 dB
Horizontal Resolution: 500 lines or greater
Video Output Level: 1 Vp-p (75 ohms)
Video Signal-to-Noise Ratio: DVD: 60 dB
MP3 Decoding: MPEG-1/2 AUDIO Layer-3
WMA Decoding: Windows Media™ Audio
BLUETOOTH®
BLUETOOTH® Version : Bluetooth V3.0
Output Power: +4 dBm Maximum (Power class 2)
HFP (Hands Free Profile) 1.6
A2DP (Advanced Audio Distribution Profile) 1.2
AVRCP (Audio/Video Remote Control Profile) 1.4
PBAP (Phone Book Access Profile)
OPP (Object Push Profile)
SPP (Serial Port Profile)
Sound Tuning
Subwoofer Level Adjustment: -10 to +10 step
High Pass Filter & Low Pass Filter: Off / 80 / 100 / 120 / 140 / 160 Hz
3 Band EQ High / Mid / Low -10 to +10 steps
General
Power Requirement: 12 V DC car battery (negative ground (earth)
Weight: 1.7 kg
Dimensions
DIN Size: 2DIN
Chassis Size (W x H x D) mm: 178 x 101 x 169 mm
